OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-87
August 17, 2010
USER WPT 1/2
Display the USER WPT 1/2 page, press [INIT REF], <NAV DATA>,<NEW USER WPT>.
The USER WPT pages allow for the creation or modification of user waypoints. This page is only available when
the USER DBASE configuration option is enabled.
When any identifier is entered and all mandatory fields are entered, CANCEL/CONFIRM prompts will appear.
Leaving the USER WPT pages without confirmation will automatically perform a CANCEL.
A. Page displayed for creation of a new fixed user waypoint:
B. After entering a new identifier and all mandatory fields or modifying data for an existing fixed waypoint
identifier that is not in the active route:
1R
2R
3R
4R
5R
6R
USER WPT 1/2
 ID/POS FREE= 457

o
.
o
.
BRG/DIS
---
T
/---NM
TYPE
>FIXED
REF WPT ID RAD/DIS
-----
o
/ NM
REF WPT POS
---
o
--.-- ----
o
--.--
<NAV DATA WPT LIST>
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
6R
USER WPT 1/2
ADFF
ID/POS FREE= 457
N45
o
12.23 W043
o
32.12
BRG/DIS
223
T
/115NM
TYPE
FIXED
REF WPT ID RAD/DIS
-----
o
/ . NM
REF WPT POS
---
o
--.-- ----
o
--.--
<CANCEL SAVE? CONFIRM>
1L
2L
3L
4L
5L
6L
DRAFT
