C. After entering DELETE on an existing user waypoint identifier:
ID [1L]:User waypoint identifier (5 characters max.).
When the identifier entered exists as a non-user waypoint, the entry is allowed and an advisory message
!DUPLICATE WAYPOINT appears. When the identifier entered exists as a user waypoint during the creation of
a new user waypoint, the entry is not allowed and an advisory message !DUPLICATE USER WAYPOINT
appears. However entering an existing waypoint identifier during user waypoint edition will trigger the display of
the NAV DATA page with the associated entered waypoint information. If a modification is in progress, entering
a new identifier will delete the previously displayed information and display the information corresponding to the
newly entered identifier. Pressing [CLR] in this field will bring the DELETE? prompt. The default value is boxes.
POS [1R]: User waypoint position in the selected coordinate system and datum. Automatically displayed if the
user waypoint identifier entered exists. Manual entry forces default value to appear in the REF WPT ID and REF
WPT POS and RAD/DIS fields and automatically updates the BRG/DIS field. The default value is boxes.
FREE: Number of user waypoint free slots in user database (458 user waypoints max.).
BRG/DIS [2L]: Bearing and distance from the current aircraft position to the waypoint. Manual entry forces
default value to appear in the REF WPT ID and REF WPT POS and RAD/DIS fields and automatically updates
the POS field. BRG and DIS values may be entered individually or simultaneously; a ‘/’ symbol preceding a
value in the scratchpad indicates only the DIS value must be updated. The values will be recomputed and
displayed at a minimum rate of once every second. The default values are dashes, and the minimum/maximum
values for the bearing are 0/360 degrees and 0/999 nm for the distance.
TYPE [3L]: FIXED waypoint type indication. The default upon entry in the page will be FIXED, as applicable.
The toggling is only possible when adding a new user waypoint.
REF WPT ID [4L]: Reference waypoint identifier with dashes as default value. Entry of an identifier will display
its position in the REF WPT POS field and the POS and BRG/DIS fields will be automatically updated.
RAD/DIS[4R]: Radial/distance from the reference position to the desired user waypoint position. The default
values are blanked, when no REF WPT POS is defined, otherwise zeros are displayed as the default values. No
entries are allowed, when the fields are blanked. Manual entry automatically updates the POS and BRG/DIS
fields. RAD and DIS values may be entered individually or simultaneously; a ‘/’ symbol preceding a value in the
scratchpad indicates only the DIS value must be updated. The minimum/maximum values for the radial are 0/360
degrees and 0/999 nm for the distance.
USER WPT 1/2
