1.6.3 Unachievable Waypoint Altitudes in Climb
ertical Speed and Distance to Go, that the aircraft will not reach
active climb waypoint:
• An UNABLE ALT CONSTRAINT message is raised
• The unachievable altitud the CLB page
e airplane
anded target speed. This climb strategy is known as “Open Climb” guidance.
nts, it is
int altitude
selected lateral mode
(e.g.:
CAUTION: The FGCP altitude must always be set to the altitude of a climb waypoint altitude that constrains
the climb path (e.g. an AT, or AT OR BELOW constraint); otherwise the aircraft will continue to
climb towards the FGCP altitude and may therefore violate the altitude constraint.
NOTE: A CHECK SELECTED ALT alert message will also be raised if the FGCP altitude is set above
an AT, or AT OR BELOW or upper limit of a WINDOW climb waypoint altitude constraint, and
the aircraft has reached an altitude where the start of capturing the altitude constraint would
normally be commanded.
If the FMS predicts, based on current aircraft V
an altitude within 150 ft of the altitude constraint associated with the
e constraint is displayed in amber on
ACT MIN FUEL CLB 1/5
CRZ ALT MAX AT (INTC)
FL240 FL400 15000A
MFUEL SPD TO (INTC)
280/.780 2308.4z/3.9nm
SPD REST
250/10000
{SCHED ENGINE OUT}
PROFILE}
UNABLE ALT CONSTRAINT
1.6.4 Open Climb Guidance
During Climb, the FMS transmits to the Autopilot system and displays on the PFD a target speed; th
tracks and holds the FMS-comm
NOTE: Although the FMS-commanded climb target speed respects all waypoint speed constrai
the responsibility of the flight crew to ensure that the aircraft respects all waypo
constraints during climb.
During Climb, the FMS will continue to manage the climb target speed regardless of the
LNAV or HDG modes).
Page F-21
