OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
FMS DISPLAY SETUP
From the IDENT 1/2 page, go to DISPLAY 1/1 page, by pressing [INIT REF] and <DISPLAY> (LSK 4L).
1R
2R
3R
4R
5R
6R
DISPLAY 1/1
<PARALLAX
<INIT/REF
1L
2L
3L
4L
5L
6L
1. Press LSK 1L and adjust display PARALLAX for proper viewing angle.
2. Press <INIT/REF> (LSK 6L).
3. Press <IDENT> (LSK 1L) to return to the IDENT 1/2 page.
Page 3-5
August 17, 2010
DRAFT
