OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-15
August 17, 2010
DME STATUS 1/1
The DME STATUS 1/1 page displays the DME stations selected by the FMS for DME-DME navigation. Up to
six stations are displayed. For each station the identifier (ID), status (STAT), frequency (FREQ) and distance
(DIS) are given. As the FMS automatically tunes available DME stations within the vicinity of the aircraft, the
display will continually change.
Display DME STATUS 1/1 page by pressing [INIT REF], <NAV STATUS> and <DME>.
DME/DME position expressed in latitude/longitude coordinates:
ID (1L, 2L, 3L): 3 or 4-character DME IDENTIFIER in the first column.
STAT (1L, 2L, 3L): Tuning STATUS in the second column.
REJ: DME station is not used in determining position (due to bad geometry).
N/A: Station not responding to tuning.
FREQ (1L, 2L, 3L): DME frequency (MHz) in the third column.
DIS (1L, 2L, 3L): DME slant range distance (nm) in the fourth column.
POSITION (5R): Displays DME/DME navigation position.
NAV STATUS [6L]: Returns to NAV STATUS INDEX 1/1 page.
DME DESEL [6R]: Access to VHF NAV DESELECT 1/1 page.
DME STATUS 1/1
ID STAT FREQ DIS
YUL 116.30 25.5
NM
IJFK N/A 109.50 NM
YJN REJ 118.00 64.5NM
PLB 118.80 12.5NM
YQA REJ 119.00 39.0NM
YUD 120.25 99.5NM
POSITION
N46
o
43.31 W078
o
46.07
<NAV STATUS DME DESEL>
To Next Page
