Esterline CMA-9000 - Hold 1;X

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-22
August 17, 2010
HOLD 1/X
Additional fields are displayed when Performance VNAV is configured – refer to Appendix F - the Performance
VNAV section for further information.
• [HOLD] If a holding FIX already exists in the route.
• Automatically accessed whenever a proposed holding fix was entered on the RTE LEGS page (e.g.
appending ‘/H’ to an existing waypoint).
Used to review and/or revise the details of either an existing or proposed holding pattern. A manually exited
holding pattern can be defined by the pilot. A holding pattern termination at an altitude or after one full circuit is
the result of the departure/arrival procedures in the database. The possible display formats are shown below.
A. Prior to EXECution (EXEC annunciator is illuminated):
B. After EXECution, but prior to hold entry:
1R
2R
3R
4R
5R
6R
MOD RTE 1 HOLD 1/1
FIX SPD/TGT ALT
KILLA 220/ 5000A
TURN DIR RNP FIX ETA
>RIGHT 1.50NM Z
INBD CRS
050
o
LEG TIME/DIS
1.0MIN/--.-NM
EXIT TYPE STATUS
MANUAL INACTIVE
<ERASE
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
6R
RTE 1 HOLD 1/1
FIX SPD/TGT ALT
KILLA 220/ 5000A
TURN DIR RNP FIX ETA
>RIGHT 1.50NM Z
INBD CRS
050
o
LEG TIME/DIS
1.0MIN/--.-NM
EXIT TYPE STATUS
MANUAL INACTIVE
<NEW HOLD
1L
2L
3L
4L
5L
6L
