OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
CONDENSED APPROACH PROCESS
The following describes the process of selecting the approach procedures.
1. MOD, ACT ROUTE - select departure/arrival index page.
2. DEP/ARR INDEX - select arrival at desired airport (origin or destination).
3. ARRIVALS - select APPROACH and APPROACH transition.
4. MOD, ACT RTE x LEGS - confirm that the approach procedure agrees with the ATC clearance, then make
the modified route active.
A detailed description of each page is contained in Appendix A.
The procedure described below is based on the approach shown in Figure 7-2, and assumes that the STAR has
already been selected and made active.
Display the DEP/ARR INDEX 1/1 page by pressing [DEP/ARR].
1. Select the desired arrival by pressing LSK 1R or 2R.
The ARRIVALS 1/X page is displayed, with the airport name included in the title line. Approaches are listed on
the right hand side of the page, followed by the runways. The selected STAR and STAR transition are
displayed on the left hand side of the page with the legend "<ACT>" beside the name. If a STAR has already
been selected, only those approaches applicable to that STAR are displayed.
2. Display the desired approach by pressing [PREV] or [NEXT] as required, and select the approach by
pressing the appropriate right hand LSK.
The approach list is replaced by the selected approach, with the legend "<SEL>" beside the name. Approach
transitions (initial approach fixes) available for the selected approach are listed below it. If no transitions are
available, the word "-NONE-" is displayed.
NOTE: Do not select a runway before the approach unless a VFR approach is planned, since this results in
only the runway threshold waypoint being loaded into the route.
3. Display the desired approach transition by pressing [PREV] or [NEXT] as required, and select the approach
transition by pressing the corresponding right hand LSK.
PANC ARRIVALS 1/1
STARS RTE 1 APPROACHES
AMOTT5 VORD06R
RUNWAYS
ELLAM2 06L
TAGER1 06R
YESKA1 14
24L
<DEP/ARR ROUTE>
Page 7-3
August 17, 2010
