OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
The list of transitions is replaced by the selected transition, with the legend "<SEL>" beside the name.
NOTE: For FMS arrivals, the selection of the approach transition may not be necessary in order to avoid
duplication of numerous legs. (The STAR procedure may lead up to the FAF already).
4. Display the first approach leg (normally the approach transition waypoint, if selected) by pressing [LEGS]
and [PREV] or [NEXT] as required.
1R
2R
3R
4R
5R
PANC ARRIVALS 1/1
STARS RTE 1 APPROACHES
AMOTT5<SEL> <SEL>VORD06R
TRANS TRANS
ODK <SEL> ANC
D173J
D350J
<ERASE ROUTE>
1L
2L
3L
4L
5L
6L
6R
Page 7-4
August 17, 2010
DRAFT
