OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Deletion of the procedure turn reference fix or the first outbound waypoint results in the deletion of the entire
procedure turn. The two outbound waypoints cannot be copied to the scratchpad, and cannot be used as
reference waypoints.
DELETION OF PROCEDURE TURNS
If an approach transition including a procedure turn has been loaded into the route, it can be readily deleted and
converted into a straight-in approach.
With the ACT or MOD RTE x LEGS 1/X page displayed:
1. Line select to the scratchpad (do not key in), the procedure turn reference fix LSK 4L.
ACT RTE 1 LEGS 1/3
042
o
36.8NM
ANC /
23 P-
ANCPTL
3
o
T 3.00NM
1L
1R
2. Move the procedure turn reference fix to the TO WPT location by pressing LSK 1L.
The procedure turn reference fix and the two outbound waypoints are deleted from the MOD route, and the
FAF waypoint becomes the TO WPT, with the correct inbound course to the FAF displayed as the default
intercept course.
NOTE: The procedure turn also can be deleted by deleting the reference fix by means of the [CLR] functional
key. However, depending on the order of the deletion and direct-to navigation actions, the intercept
inbound course may have to be entered manually since the default value will be that of the original leg
inbound to the reference fix.
2R
3R
4R
5R
6R
18
ANCPTR
R053
o
CRS 4.86NM
8
o
P-T 2.25NM
ANC FAF
053
o
CRS 5.09NM
RW06R /oMAP
<RTE 2 LEGS LEGS ETA>
2L
3L
4L
5L
6L
Page 7-17
August 17, 2010
DRAFT
