OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
VHF1 [1L]: Display and modify active/standby preset number and channel of the VHF1 radio. Selecting LSK 1L
when the scratchpad is empty will toggle the standby and the active preset/frequency.
VHF2 [1R]: Same as above, but referencing VHF2 instead of VHF1 and LSK 2R instead of LSK 1L.
NOTE: It is possible to have "-" in one or both of the active and standby fields after FMS maintenance. Toggling
is not allowed when "-" are present in the standby field. Then, a frequency needs to be entered in the
standby field first before the active/standby field toggling is allowed, otherwise a warning message will
be displayed in the scratchpad.
SQUELCH [3L]: When configured and for VHF-422 and VHF-4000 VHF radios only, toggles COM1 radio
squelch status ON or OFF.
SQUELCH [3R]: Same as above, but referencing COM2 instead of COM1.
VOICE/DATA [5R]: When voice/data control is configured and for the VHF-422 and VHF-4000 VHF radios only,
allows the crew to place the VHF radio in either the VOICE or DATA mode.
RADIO [6L]: Access to the RADIO top level page where the VHF is located.
LIBRARY [6R]: Access to the access to the VHF Library page.
COMMUNICATION RADIOS (VHF RADIO Page 2/2)
This page allows the pilot to control the operation of 2 VHF units.
NOTE: This page is only displayed if radio test is configured.
Display the second VHF 2/2 page from the horizontal configuration by pressing [RADIO], [NEXT], <VHF#>,
[NEXT].
NOTE: The COM VHF radio equipment name can also be configured as “COM" or "VHF".
The VHF ident suffix "x" (e.g. VHF, VHF1...) and the side (left or right) where the COM units appear is
depending on the installation configuration. The tables below provide examples.
VHF 2/2
VHF1 TEST VHF2 TEST
>READY READY<
<RADIO
Page 13-18
August 17, 2010
