OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
VHF LIBRARY 1/N PAGE
This page allows the pilot to view and modify the preset numbers, identifiers and frequencies that are stored in
the VHF radio library.
Display VHF LIBRARY 1/N page from the horizontal configuration by pressing [RADIO], [PREV]…, <VHF> or
[RADIO], <VHFx> <LIBRARY>.
VHF LIBRARY 1/N
PR/IDENT/FREQ(MHz)
02/KFTE /120.025
ACT1
04/ABC /121.050 --
SBY1
07/CYUL1/122.075 --
ACT2
11/ /121.075 --
SBY2
3/A /120.050 --6
<VHF RADIO LIBRARY>
The maximum number of VHF LIBRARY entries is 99. The maximum number of VHF LIBRARY pages is 20.
The [NEXT] and [PREV] keys are used to scroll forward or backward in the preset numbers.
[1L],[2L],[3L],[4L],[5L]: Display and modify VHF library entries.
• To add a new record in the library, key into the scratchpad the preset number, the identifier and the frequency,
each separated by the slash symbol (“/”) and press any of the line select keys that are associated with a library
record (LSK 1L, LSK 2L, LSK 3L, LSK 4L or LSK 5L). The new record will be added to the library. The library
will also be re-sorted and the new entry will be displayed. If the record (identified by preset number) was
already existing then it will be overwritten. An ident is restricted to alphanumeric characters, e.g. “+” and “-” are
not allowed as ident characters.
• A preset number must be specified.
• Also entry of an existing preset number followed by a slash and nothing else will, upon pressing a line select
key associated with a library record, display the entered preset without changing its ident or frequency.
• To delete a record from the library, Press [CLR] key to display DELETE in the scratchpad, and press the line
select key (LSK) corresponding to this record. The record will be deleted and the library will be resorted.
• To modify a library record enter the parameter to be modified using the “slash” rule, e.g. if nothing is entered
before the slash then the field remains unchanged.
• E.g.: To change 04/ABC /111.050 to 04/ABC /112.075 at LSK 2L press the following keys:
a) “//112.075” and LSK 2L or
b) LSK 2L to transfer the current library record into the scratchpad, press the [CLR] key 5 times to erase
the 5 last characters of the frequency, then enter the new frequency by pressing [2],[.],[0],[7],[5] and
press the LSK 2L to enter the modified record into the library.
• In order to transfer a library record to the active or standby field of the VHF LIBRARY page first press the LSK
corresponding to library record. This places the preset number, the identifier and the frequency in the
scratchpad. Then press LSK 1R, LSK 2R, LSK 3R or LSK 4R (as desired) to transfer the contents of the
scratchpad. The identifier will not be displayed on the radio page field even though it was displayed in the
scratchpad.
Page 13-23
August 17, 2010
To Next Page
