OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
E/O SCHED
The E/O SCHED page is used to select the current Engine-Out speed sub-mode that will be flown for the
Engine-Out Cruise or Drift-Down. Only one Engine-Out speed sub-mode can be selectable at any time.
Display E/O SCHED page by pressing:
[VNAV], <SCHED> (When in Engine-out Cruise or Drift-Down mode).
A. Initial display after the E/O SCHED page was accessed and the default speed sub-mode is selected.
1R
2R
3R
4R
5R
6R
ACT E/O SCHED 1/1
SPD SCHED
GREEN DOT
>LRC
E/O CRZ>
1L
2L
3L
4L
5L
6L
B. The sub-mode displayed in [2L] has been selected.
1R
2R
3R
4R
5R
6R
MO
D
E/O SCHED 1/1
SPD SCHED
>GREEN DOT
LRC
<ERASE E/O CRZ>
1L
2L
3L
4L
5L
6L
TITLE: The title displays:
• "MOD" if the EXEC key is illuminated; otherwise
• "ACT" if E/O Cruise or Drift-Down is active; otherwise
• Blanks
followed by E/O SCHED.
Page RRJ-A-65
August 17, 2010
DRAFT
