Esterline CMA-9000 - Vnav Profile 1;2

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
B. Pressing the LSK toggles the display between target speeds/crossing altitudes and speeds/altitudes
constraints (similar to the LEGS page) when a green arrow is displayed in column 24.
C. Values that exceed the aircraft vertical performance envelope limits are displayed in amber (speed, vertical
speed, altitude constraint, temperature compensated altitude, climb in descent (altitude)).
D. The first cruise waypoint with a target or predicted speed that is limited to respect the aircraft speed
envelope is displayed with its speed displayed in amber.
1R
2R
3R
4R
5R
VNAV PROFILE 1/2
1210FPM 2.4°
D173J 280/ 12000 <
1700FPM 2.6°
D233J 280/ 13000 <
-- 25.7NM FROM D233J --
(T/C) .680/ FL300
-- 15.2NM FROM LACOU --
(S/C) .690/ FL300
-- 5.5NM FROM S/C --
SECHE .690/ FL320 <
<CLIMB DES FORECAST>
1L
2L
3L
4L
5L
6L
6R
1R
2R
3R
4R
5R
VNAV PROFILE 2/2
-- 10.1NM FROM PPOS --
(S/C) .690/ FL300
-- 5.5NM FROM S/C --
SECHE .690/ FL320
-- 102NM FROM MANAK --
(T/D) .690/ FL320
-3200FPM -7.5°
AJAX 280/ 15500
-- 15.2NM FROM AJAX --
(E/D) 220/ 4000
<CLIMB DES FORECAST>
1L
2L
3L
4L
5L
6L
6R
VNAV PROFILE 2/2
0 FPM 0.0°
D285P 250/ 6000 <
-- 4.6
NM FROM D285P --
(T/C) 250/ FL100
BPK01 308/ FL100
-- 2.5NM FROM D078Z --
(T/D) 220/ FL100
-1200FPM -2.8°
D087W 220/ 8000 <
<CLIMB DES FORECAST>
1L
1R
2R
3R
4R
5R
6R
2L
3L
4L
5L
6L
Page RRJ-A-41
August 17, 2010
DRAFT
