Esterline CMA-9000 - Progress 1;4; Hold 1;X

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
HOLD 1/X
Only VNAV related items and functionalities are described in this document section. Refer to the core pages
document for description of fields shown on the page and not documented in this section,
Refer to core pages document for page access.
SPD/ALT [1R]: A pilot-entered speed will trigger an OUT OF RANGE message if the entered speed is outside
the aircraft speed envelope limits.
HOLD TIME [3R]: Displays the maximum holding time for the aircraft to reach its destination with fuel reserves
available.
The title and data field are only displayed for HM legs (i.e. holding pattern with manual termination). The data
field is only computed and displayed for an active hold or, if a hold is not currently active, the nearest
downstream hold. This is true for the active and modified route when a valid profile exists.
.
BEST SPD [4R]:
Displays the best speed (corresponds to the maximum endurance speed).
The title and data fields are only displayed for manually terminated holding pattern. The data field is only
computed and displayed for an active hold or, if a hold is not currently active, the nearest downstream hold. This
is true for the active and modified route when a valid profile exists.
1R
2R
3R
4R
5R
RTE 1 HOLD 1/1
FIX SPD/ALT
KILLA 208/ 5000A
TURN DIR FIX ETA
>RIGHT 1424.5Z
INBD CRS HOLD TIME
050
° 01+45.0
LEG TIME/DIS BEST SPD
1
MIN/--.-NM 208KT
EXIT TYPE STATUS
MANUAL
IN PROGRESS
<NEW HOLD
1L
2L
3L
4L
5L
6L
6R
