OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
NAVIGATION DISPLAYS
APPENDIX C-1
NAVIGATION DISPLAYS – ARINC 702-TYPE EFIS
INTRODUCTION
The FMS information on the Navigation Display can be viewed in one of two modes: MAP or PLAN. The MAP
mode can present the aircraft symbol in the center of display (CENTER mode) or in the lower part. The two
Navigation Display modes and the CENTER mode are selected via the EFIS control panel.
MAP
MODE RANGE
10 640
32020
16040
80
POS NAV AID ARPT RTE DATA
DH
CHSI
PLAN
CADI
CTR
VOR/ILS
KLM00049
ON ON ON ON ON
Typical EFIS Control Panel
Page C-1
August 17, 2010
