OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-27
August 17, 2010
IDENT 1/2
Additional fields are displayed when Performance VNAV is configured – refer to Appendix F - Performance
VNAV section for further information.
This page displays the effective expiry dates for the current and next cycle databases and enables the pilot to
manually select the active navigation database. The loaded custom database and user database (if configured)
are also identified. The page allows the identification of the configured software in the FMS and provide validity
check for the configuration.
• Display the IDENT 1/2 page by pressing [INIT REF] and <IDENT> (LSK 1L) or automatically after power on if
the default power-up page is configured to IDENT.
NAV DATABASE (1L,2L): Navigation database identification.
OP PROGRAM (3L): Operational Program number.
CUSTOM DATABASE (4L): Displays the custom database Identifier. Up to 8 characters may be shown.
Stars “********” are shown when no custom database is loaded. Blanks are shown when the database identifier
is not valid.
USER DATABASE (5L): Displays the user database Identifier. Up to 9 characters may be shown. Stars
“********” are shown when no user database is loaded. Blanks are shown when the database identifier is not
valid or the loaded database modified. This user database displayed Identifier is only available when the USER
DBASE configuration option is enabled.
SETUP [6L]: Access to SETUP 1/1 page.
ACTIVE [1R]: Displays active database effectivity date. To select the second database as the active database.
Press LSK 2R to copy the second database date to the scratchpad. Press LSK 1R to select it as the ACTIVE
DATABASE. The current active database can be selected when on the ground. Doing so will clear any
previously loaded flight plan.
SECOND [2R]: Displays second database effectivity date. Keypress will copy this date into the scratchpad.
CFG NO (3R): Configuration CRC checksum. This number is verified against the information in the Installation
Flight/Line Manual by maintenance personnel during system installation.
1R
2R
3R
4R
5R
6R
FMS1 IDENT 1/2
NAV DATABASE ACTIVE
KLMWW0697
OCT10-NOV06/03
SECOND
KLMWW0697
NOV07-DEC04/03
OP PROGRAM CFG NO
614876-xxx.xx 00777
CUSTOM DATABASE DATE
EC-RTEST MAR21/04
USER DATABASE DATE
EC-UDTEST MAR21/04
<SETUP POS INIT>
1L
2L
3L
4L
5L
6L
