OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
A. INACTIVE ROUTE MANIPULATIONS (SUMMARY)
1. Using the procedures outlined in Section 3, enter the origin, destination, and waypoints, or select a
stored custom route as the inactive route. Next, press <CONFIRM>, (LSK 6R) to save the modifications
or <CANCEL> (LSK 6L) to delete them.
NOTE: In the case of a dual/triple FMS installation, the inactive route modification is cross-talked to the off-side
FMS upon pressing the <CONFIRM> prompt.
If the EFIS model permits, the EFIS displays the inactive flight plan in cyan when an inactive route page is
displayed on the FMS.
2. The inactive route is edited directly on the ROUTE, LEGS, DEP/ARR and HOLD pages. Both active and
inactive routes have their own independent set of ROUTE, LEGS, DEP/ARR and HOLD pages.
3. To ACTIVATE the inactive route, press LSK 6R on the inactive RTE page, followed by pressing the
[EXEC] key.
NOTE: The following RTE COPY procedures highlight the basic steps required to select, then activate a second
route.
B. INACTIVE ROUTE MANIPULATIONS (DETAILED STEPS)
1. To copy the active route, e.g. RTE 1, to the inactive route, press LSK 4L of the inactive RTE page. RTE
1 remains active and continues to be used for navigation.
2. Press LSK 6R to CONFIRM copying of the route.
NOTES:
• The copied route contains the current active TO and subsequent waypoints. Overflown waypoints are
not copied.
• In the case of a dual/triple FMS installation, the inactive route is crosstalked to other FMU's upon each
CONFIRM of flight plan changes and upon synchronization.
• No trip predictions are performed on the inactive route.
1R
2R
3R
4R
5
R
RTE 2 1/2
ORIGIN DEST
KSEA PANC
RUNWAY FLT NO
23R AS007
ROUTE
KSEAPANC1
<COPY RTE 1 CO RTES>
USER RTES>
<CANCEL SAVE? CONFIRM>
1L
2L
3L
4L
5L
6L
6R
