OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
3. Press [LEGS] to display the RTE 2 waypoints. Modify the RTE x LEGS page as required to build a new
flight plan based on the current active route.
4. When changes are completed, press the [RTE] key to access the RTE 2 page.
5. Press <ACTIVATE> (LSK 6R) to the inactive route.
6. The RTE 2 LEGS page is displayed. Press the [EXEC] key to confirm activation of RTE 2.
RTE 2 LEGS 1/5
299
o
39.6NM
CAFTA
298
o
154NM
YZP
307
o
86.7NM
MOCA1
306
o
165NM
BKA
282
o
197NM
KILLA
<RTE 1 LEGS LEGS ETA>
RTE 2 1/2
ORIGIN DEST
KSEA PANC
RUNWAY FLT NO
23R AS007
ROUTE
KSEAPANC1
<COPY RTE 1 CO RTES>
USER RTES>
RTE 2
<RTE 1 ACTIVATE>
MOD RTE 2 LEGS 2/4
299
o
39.6NM
CAFTA
298
o
154NM
YZP
307
o
86.7NM
MOCA1
306
o
165NM
BKA
282
o
197NM
KILLA
<ERASE LEGS ETA>
Page 5-32
August 17, 2010
