AIR MILES (2R): Display the total nautical miles travelled. It is only reset after a cold start followed by a takeoff;
otherwise, if a landing is detected, the value will be frozen and resumed after take off.
LANDINGS [3R]: Display the number of landings since the last cold start on the ground. The landings count
is increased after every air ground transition. The landings count is reset after a cold start once the aircraft is on
ground.
FUEL 1/2 page
Refer to Appendix F - Performance VNAV Section for further information.
GLONASS STATUS 1/2
Display the GLONASS STATUS 1/2 page by pressing [INIT REF], <NAV STATUS> and <GLONASS>.
OP MODE (1L): GLONASS receiver operational mode.
• TEST: Self-Test Mode.
• INI: Initialization Mode.
• ACQ: Acquisition Mode.
• NAV: Navigation Mode.
• NAV/ALT: Altitude/Clock Aided Navigation Mode.
• NAV/DIFF: Differential Navigation Mode.
• NAV/AIDED: Direction/Speed Aided Navigation Mode.
• FAILED: Failure detected.
SAT VIS (2L): Number of healthy satellites visible.
SAT TRK (2R): Number of satellites tracked.
HOR FOM (3L): Horizontal Figure Of Merit (meters).
1R
2R
3R
4R
5R
6R
GLONASS STATUS 1/2
OP MODE
NAV
SAT VIS SAT TRK
8 5
HOR FOM VER FOM
20
M 65M
HOR DOP VER DOP
1 2
HOR INT
O.20
NM
<NAV STATUS
