OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
F. SAVING THE DATABASE FOR USE BY ANOTHER AIRCRAFT
The user data accumulated during the missions can be retrieved from the FMS using a serial (High Speed)
data loader. This data can then be loaded into any FMS.
1. By pressing [INIT REF], [NEXT], <DATA LOAD>, the DATA LOAD 1/1 page is displayed. Toggle the
TYPE prompt (LSK 1L) till it indicates USER_DATA.
2. Press SAVE (LSK 6R) to start data download from the FMS to the Data Loader Unit (only when aircraft
on ground).
1R
2R
3R
4R
5R
DATA LOAD 1/1
TYPE
>USER_DATA
STATUS
IDLE 0000
KB
LOAD>
<INIT/REF SAVE>
1L
2L
3L
4L
5L
6L
6R
1R
2R
3R
4R
5R
DATA LOAD 1/1
TYPE
>USER_DATA
STATUS
SAVING TO DISK 0014KB
56%
<ABORT
<INIT/REF
1L
2L
3L
4L
5L
6L
6R
