OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
ACTIVE DATABASE SELECTION
CAUTION: When the active database is changed, any existing active route is deleted.
1. Copy the SECOND cycle date into the scratchpad, by pressing LSK 2R.
2. Move the cycle date into the ACTIVE field by pressing LSK 1R.
The active database cycle is replaced by the second database cycle, as shown by the interchange of cycle
dates. The active database cycle is displayed in large font. The active database can only be changed on
the ground.
Display the IDENT 2/2 page by pressing [INIT REF], <IDENT> and [NEXT].
This page displays the identification and model of the magnetic variation along with the aircraft, engine and
policy related parameters for performance VNAV.
FMS1 IDENT 2/2
AIRCRAFT ENGINES
SSJ100 SAM-146 G
MAGVAR MODEL POLICY
2005 (DEF) SSJ100 POL
<SETUP POS INIT>
1L
2L
3L
4L
5
L
6L
1R
2R
3R
4R
5R
6R
