OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
TCAS MODE [4R]: Displays and allows section of one of the following TCAS mode options: STANDBY, TA/RA
and TA. Selection of TA/RA or TA will automatically force the ATC MODE (4L) to NORMAL. If the ATC MODE
(4L) reverts to STANDBY or ALT_RPTG_OFF, then the TCAS mode (4R) will automatically revert to STANDBY.
EMERGENCY [5R]: Available when the configured emergency code is not 0000, otherwise the field is blank.
Pressing this soft key will transmit the configured emergency code to the transponder and force the transponder
mode (4L) to NORMAL. When pressed, the font changes to large inverse green as long as the transponder is
active. Selection of EMERGENCY will also initiate the IDENT function (refer to [5L] for additional details).
When an ATC hijack pushbutton is installed in the cockpit, the crew can activate it and, as a result, the FMS
radio management function activates the configured ATC hijack code (default is 7500).
TRANSPONDERS (XPDR/TCAS Page 2/2)
This page allows the pilot to control the operation of 2 XPDR/TCAS units.
NOTE: This page is only displayed if the transponder test option is configured.
NOTE: This page may no longer be displayed once airborne if configured accordingly.
Display the second XPDR/TCAS page from the horizontal configuration by pressing [RADIO], <XPDR>, [NEXT].
XPDR/TCAS TEST [5L]: Toggles the active transponder test status and results. Toggle options for test status are
READY, CONFIRM? and STARTED. Pressing LSK the first time causes ARMED to appear the second press
initiates the tests. Test result is: PASS or FAIL or TIMEOUT.
RADIO [6L]: Access to the RADIO top level page where the ATC/TCAS is located.
XPDR/TCAS 2/2
XPDR/TCAS TEST
>READY
<RADIO
Page 13-22
August 17, 2010
To Next Page
