ESS FAILURE 1/1
The ESS FAILURE 1/1 page displays the error messages when the communication with the selected external
sub-system is failed.
Refer to Installation Flight/Line manual for additional details.
FIX INFO 1/1
The FIX page provides bearing or course and distance information relative to an entered FIX. Distance To Go
(DTG) and ETA are displayed for radial, distance and abeam intersections. The FIX entry must be a valid
waypoint or navaid. Radial/Distance (RAD/DIS) entries can be radials or distances from the entered FIX. Radial
or distance or abeam intersection data may be entered as waypoints in the route by line selecting into the
scratchpad and transferring to the RTE LEGS 1/X page.
Display FIX INFO 1/1 page by pressing [FIX] or [INIT REF], <FIX INFO>.
FIX [1L]: FIX identifier. Valid entry is any airport, navaid or waypoint identifier found in the
navigation/customercustom/temporary waypoints/user waypoints databases or in the active route. Displays
selected fix on EHSI. Entry of seven-character waypoint is allowed.
RAD/DIS [3L, 4L]: Radial and/or distance from FIX. If radial line or distance intersects the active route,
distance to go and ETA at the intersection are displayed. Radial entry is displayed on the EHSI as a radial line.
Distances are displayed on the EHSI as a circle around the fix.
ABEAM [5L]: Initially, the ABEAM prompt is displayed. Line selecting ABEAM displays radial/distance, distance
to go and ETA at the abeam intersection.
1R
2R
3R
4R
5R
6R
FIX INFO 1/1
