OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
CRZ WIND [3R]: Entry and display of the forecast wind at the top-of-climb.
Valid range for top-of-climb wind direction/speed is: 0
T
-359
T
/0-999kt. Deletion of the manual entry is allowed.
Manual CRZ WIND entry is displayed in large white font. When no value is entered, the data field displays "---
T
/-
--". The title and data field are blank upon sequencing the first cruise waypoint with a wind entry.
TRANS ALT [5R]: Entry and display of the Transition Altitude.
Manual entry overrides the value extracted from the navigation database, if available, or the default
configuration value. Valid range for the Transition Altitude entry is between 0ft to 45,000ft. Deletion of a
manually entered Transition Altitude reverts to the value extracted from the navigation database, if available, or
to the default value. Deletion of Transition Altitude values extracted from the navigation database or default
value is not allowed.
Manual entry is displayed in large white font. Default value or value extracted from the navigation database is
displayed in small white font.
TAKEOFF [6R]: Enables direct access to the TAKEOFF REF 1/1 page if TAKEOFF speeds are in the PDB.
TAKEOFF REF 1/1
While on ground, allows manual entry and display of the takeoff speeds and, entries for FLEX takeoff
temperature or derated takeoff thrust. This page also displays the default values of the Thrust Reduction Height
and Acceleration Height extracted from the Policy File and allows the crew to manually overwrite these values.
When airborne, takeoff data entry is inhibited.
The following range checking is applied to the entered takeoff speeds:
V
1
<= V
R
< V
2
Any entry that does not respect this criteria will not be accepted and an !OUT OF RANGE entry error message
will be displayed.
Display the TAKEOFF REF 1/1 by pressing [PERF INIT], <TAKEOFF> or [INIT REF], <TAKEOFF>.
Crew have entered the takeoff speeds and no derated or FLEX takeoff temperature. Thrust reduction height
and acceleration height display the default values extracted from the Policy File.
TAKEOFF REF 1/1
V1 DERATE-FLEX
140KT ---
VR ACCEL HT
143KT 3000FT
V2 THR RED HT
146KT 1500FT
FLAP RETR
144KT
SLAT RETR GREEN DOT
185KT 200KT
<INIT/REF ROUTE>
1L
1R
2R
3R
4R
5R
6R
2L
3L
4L
5L
6L
Page RRJ-A-4
August 17, 2010
DRAFT
