ERASE FIXES [6L]: Removes all downtrack fixes from display. A downtrack fix can also be deleted by using the
CLR key.
DTG (3L,4L,5L): Distance to go along the flight plan to the downtrack fix. The field becomes blank after the
downtrack fix was overflown.
ETA (3L,4L,5L): Estimated Time of Arrival at the downtrack fix. After the downtrack fix was overflown (the DTG
field is blank), this field displays the actual time of arrival at the downtrack fix.
NOTE: On ground, ETE fields are blank.
REF [1R]: FR: Radial (RAD) from FIX to present position. TO: Course (CRS) from present position to FIX. The
default value is the last selected value, which is restored after a power interruption.
RAD/DIS(1L): Displayed when REF is FR. Radial/Distance from FIX to present position.
CRS/DIS(1L): Distance when REF is TO. Course/Distance to FIX from present position.
NOTE: Downtrack fixes are not possible with seven-character waypoints.
FLIGHT LOG 1/1
Display FLIGHT LOG 1/1 page by pressing [INIT REF], [NEXT] and <FLIGHT LOG>.
TAKEOFF (1L): Display of initial takeoff zulu time hours and minutes. The time is reset after a cold start on
ground and set after a cold start on ground followed by a ground-air transition.
INFLIGHT (2L): Display of in-flight duration in hours and minutes. It is only reset after a cold start followed by
a takeoff; otherwise, if a landing is detected, the value will be frozen and it will be resumed after the following
take off.
INIT/REF [6L]: Returns to INIT/REF INDEX 2/2 page.
LANDING (1R): Display the last landing zulu time hours and minutes when the aircraft is on the ground.
When the aircraft is airborne, blanks are displayed. The last landing time is updated after each air to ground
transition.
FLIGHT LOG 1/1
TAKEOFF LANDING
1235.4
Z 1335.4Z
INFLIGHT AIR MILES
01+00.0
560NM
LANDINGS
12
<INIT/REF
