OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
ROUTE 2 OPTION
When configured with RTE 2 option, two independent routes (RTE 1 and RTE 2) may reside in the FMS at the
same time. The FMS allows activation of one route as the active flight plan. The other flight plan is stored as
the inactive route. The default route at power-up, with both routes empty, is RTE 1.
The inactive route may be manually created or selected from the stored custom routes. It may also be copied
from the active route. The procedures to create, select, and/or edit the inactive route are identical to those of
the active route.
1. Display the ACT RTE x 1/X page by pressing [RTE] (a route has been previously entered and executed).
2. Access the inactive route by pressing LSK 6L (e.g. RTE 2).
NOTE: The inactive route pages are displayed in monochrome cyan to distinguish them from the active route
pages.
1R
2R
3R
4R
5R
ACT RTE 1 1/2
ORIGIN DEST
KSEA PANC
RUNWAY FLT NO
23R AS007
ROUTE
KSEAPANC1
CO RTES>
USER RTES>
OFFSET
<RTE 2 R0.0NM
1L
2L
3L
4L
5L
6L
6R
RTE 2 1/2
ORIGIN DEST
 
RUNWAY FLT NO
----- --------
ROUTE
----------
<COPY RTE 1 CO RTES>
USER RTES>
<RTE 1 PANC ACTIVATE>
1R
2R
3R
4R
5R
6R
1L
2L
3L
4L
5L
6L
