OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
WAYPOINT INFORMATION FROM THE NAVIGATION DATABASE
1. Key in the desired identifier (waypoint, navaid, airport, temporary waypoint), or copy it into the scratchpad
from any other page.
2. Display the NAV DATA 1/1 page by pressing [INIT REF], <NAV DATA> (LSK 1R).
3. Move the scratchpad entry to the ID field by pressing LSK 1L.
4. Detailed information appropriate to the selected identifier type is displayed. If the identifier is not contained
in the database, the "!NOT IN DATABASE" advisory message is displayed in the scratchpad.
DUPLICATE IDENTIFIER SELECTION
The SELECT WPT 1/X page is automatically displayed when multiple occurrences of the entered identifier are
found in the navigation database. The duplicated identifier is incorporated into the page title line. Duplicated
identifiers are listed on as many pages as necessary, in order of increasing distance from the previous waypoint.
NOTE: Display the desired coordinates by pressing [NEXT] as required and then select it by pressing the
appropriate left or right hand LSK.
SELECT WPT RNG 1/1
SAM SK VHF NAV
N05
o
59.50 W073
o
25.30
SPA AD WAYPOINT
S12
o
19.50 E134
o
53.30
CAN CY AIRPORT
N45
o
27.00 W073
o
44.00
NAV DATA 1/1
YUL
WPT POS
N45
o
28.08 W073
o
44.48
BRG/DIS 295
T
/91.0NM
DATABASE NAVIGATION
REGION CAN CY
TYPE/CLASS VORDME/H/C
ELEVATION +230
FT
FREQ 116.30
MHZ
DECLIN W016
o
<NEW USER WPT
Page 5-27
August 17, 2010
