OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
CLB SCHED 1/1
The CLB SCHEDule page is used to select the current CLIMB speed sub-mode that will be flown for the entire
profile or the climb phase of flight only. A maximum of one Climb speed sub-mode can be selected at any time.
Display the CLB SCHED 1/1 page by pressing:
[VNAV], <SCHED> (When in Climb mode)
A. Initial display after the CLIMB SCHED page was accessed and the default speed mode is selected.
1R
2R
3R
4R
5R
6R
ACT CLB SCHED 1/1
SPD SCHED
MIN FUEL
CLIMB>
1L
2L
3L
4L
5L
6L
B. A manual speed has been entered on the climb page and the sub-modes are deselected.
1R
2R
3R
4R
5R
6R
ACT CLB SCHED 1/1
SPD SCHED
>MIN FUEL
CLIMB>
1L
2L
3L
4L
5L
6L
Page RRJ-A-12
August 17, 2010
DRAFT
