Esterline CMA-9000 - USER DATABASE MANAGEMENT

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
USER DATABASE
The FMS contains a User database which is used to store user waypoints and user routes. User waypoints can
be:
• entered from the scratchpad or
• received from the digital map or
• loaded from or saved to the DLU.
It is also possible to associate the existing route (MOD/ACT) with a user route created by the user and stored in
the User database.
User waypoints can be defined as different types:
• Waypoint (fixed);
• Airport;
A new user waypoint can be created on the USER WPT pages either by directly entering the coordinates of
the new waypoint or by using a known position as reference and a radial/distance from the reference position
to the desired user waypoint position.
A. MANUAL ENTRY OF A FIXED USER WAYPOINT IN THE DATABASE
Display the NAV DATA 1/1 page by pressing [INIT REF], <NAV DATA> (LSK 1R).
1. Press the <NEW USER WPT> prompt at LSK 6R.
1R
2R
3R
4R
5R
6R
USER WPT 1/2
 ID/POS FREE= 459

o
.
o
.
BRG/DIS
---
T
/---NM
TYPE
>FIXED
REF WPT ID RAD/DIS
-----
o
/ NM
REF WPT POS
---
o
--.-- ----
o
--.--
<NAV DATA WPT LIST>
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
NAV DATA 1/1
ID
-----
<NEW USER WPT DES+SAR>
1L
2L
3L
4L
5L
6L
6R
