OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-51
August 17, 2010
FMS POS [1L]: Displays FMS present position and the selected navigation mode.
MODE [2L]: Displays the names for each of the navigation modes that are configured. The active
navigation mode will be highlighted.
NOTE: For LASEREF_V: N corresponds to the number of the IRS used for the triple mix solution.
STS (2L): Displays the current status of each navigation mode. The following are the possible values for each
navigation mode:
GPS (refer to NOTE 2)
FAIL Fault mode
ACQ Acquisition mode
INI Initialization mode
NAV Navigation mode
AID Direction/speed aiding
mode
ALT Altitude/clock aiding
mode
DIF Differential mode
DSEL Deselected
DME/DME VOR/DME
NAV Navigation mode NAV Navigation mode
ACQ Acquisition mode ACQ Acquisition mode
CONV Converging mode CON
V
Converging mode
FAIL Fault mode FAIL Fault mode
DSEL Deselected DSEL Deselected
NOTE 1: ‘*’ are displayed when the status labels are not received from the sensor, and blanks are displayed
when the status labels have NCD SSMs.
NOTE 2: Some configured equipment may provide only a subset of these modes. Refer to the GPS 1/2
status page.
For LASEREF_V:
IRS
ALIGN ALIGN mode
NAV Navigation mode
ATT ATTITUDE mode
DSEL Deselected
DIS (2L): Display the distance in nautical miles between the FMS present position (FMS POS) and each
navigation mode positions (only if sensor is in NAV).
ACCUR (2R): Displayed only if the LSK is toggled to display ACCUR. Display the estimated navigation
accuracy (95%) of each navigation mode.
