OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-50
August 17, 2010
POS INIT/REF 2/3 (if IRS interface is configured)
Display the POS INIT/REF 2/3 page by pressing [INIT REF], <POS INIT> and [NEXT] or [INIT REF], <IDENT>,
<POS INIT> and [NEXT].
The FMS continuously monitors and displays the position range and bearing from each navigation mode
position with respect to the selected navigation solution (FMS POS), and the accuracy of the navigation sensor
positions.
Accuracy and bearing share the same column and toggling between the two is done with LSK [2R]. Accuracy is
always displayed by default upon entering the page.
A. This display is shown when in LAT/LONG and ACCURACY selected and FMS is airborne.
B. This display is shown when in LAT/LONG and BEARING selected and FMS is airborne.
POS INIT/REF 2/2
FMS POS GPS
N47
o
32.42 E122
o
18.51
MODE STS DIS ACCUR
<
GPS NAV 0.13 0.17NM
DME/DME NAV 1.60 2.73NM
VOR/DME ACQ NM
IRS NAV 0.24 0.36NM
<SETUP NAV STATUS>
POS/INIT REF 2/2
FMS POS GPS
N47
o
32.42 E122
o
18.51
MODE STS DIS BRG
<
GPS 3D 0.00 5
o
DME/DME NAV 1.60 112
o
VOR/DME ACQ
o
IRS(xN) NAV 0.24 33
o
<SETUP NAV STATUS>
