OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
5. Close-up the route discontinuity if present, as described in Section 5.
6. Verify the course, distance, speed/altitude advisory (if displayed), and procedural leg type information of
each approach leg in turn, including the missed approach procedure, pressing [NEXT] as required to display
all legs.
7. Make the selected approach and approach transition active by pressing [EXEC].
On re-display of the ARRIVALS page, the active approach and approach transition are shown with the
"<ACT>" legend beside the name.
1R
2R
3R
4R
5R
MOD RTE 1 LEGS 2/3
042
o
36.8NM
ANC
233
o
P-T 3.00NM
ANCPTL
188
o
P-T 2.25NM
ANCPTR
R053
o
CRS 4.86NM
ANC FAF
053
o
CRS 5.09NM
RW06R /oMAP
<ERASE LEGS ETA>
1L
2L
3L
4L
5L
6L
6R
1R
2R
3R
4R
5R
MOD RTE 1 LEGS 3/3
053
o
CRS 0.74NM
(544)
R200
o
HDG 12.4NM
(INTC)
173
o
CRS 13.5NM
NAPTO
-----
<ERASE LEGS ETA>
1L
2L
3L
4L
5L
6L
6R
Page 7-6
August 17, 2010
DRAFT
