OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
0703003
INTERCEPT
FIX
NEXT
WAYPOINT
SET UP DIRECT - TO INTERCEPT
LEG ON MCDU AND EXECUTE
PROCEDURE.
DISENGAGE
LNAV
2
1
FLY HEADING SELECT MODE
UNTIL ON DESIRED HEADING
3
ENGAGE
LNAV
4
TRACK IS
MANTAINED
5
INTERCEPT
COURSE
CAPTURE
6
INTERCEPT
COURSE
TO FIX
Figure 9-2 Direct-To/Intercept Phases (Heading Hold Mode)
2. If the present aircraft track/heading does not cross the intercept leg or the track angle error is larger than
135-degree, then:
a. If the cross-track distance is greater than the 45-degree leg capture distance, the FMS displays the
“NOT ON INTERCEPT TRK” message and disengages LNAV mode .
b. If the cross-track distance is less than the 45-degree capture distance, path capture is passed over
to the normal FMS steering function. No advisory message is displayed.
Page 9-5
August 17, 2010
