OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Operating Frequencies/Channels and Ranges:
The operating frequencies/channels for the Navigation and Communication radios are shown in the table below.
An error message will appear in the scratchpad if invalid entries are made.
RADIO LOWER LIMIT UPPER LIMIT INCREMENT
VOR/ILS/ DME 108.00 MHz 117.95 MHz
(VOR/ILS) 135.95 (DME)
50 kHz
ADF 190.0 kHz 1799.5 kHz 0.5 kHz
TRANSPONDER 0 (octal) 7777 (octal) 1
VHF 118.000 MHz 136.975 MHz 25 kHz
HF 2.0000 MHz 29.9999 MHz 100 Hz
ILS 108.00 MHz 111.95 MHz 50 kHz
MLS 500 699 1
NOTE: All values in the table are inclusive.
