LOC/RAD [2L], [2R]: Depending on the active frequency, the following is displayed:
• VOR radial when VOR frequency is tuned; or
• VOR LOCalizer course when a LOCalizer frequency is tuned.
SEL CRS [3L], [3R]: Used to enter the VOR1/2 selected course. The field title and datafield are blank if the
corresponding VOR has not been successfully displayed in the LSK 1L or LSK 1R datafield.
DME [5L], [5R]: Displays the DME slant range when VOR or LOCalizer frequency is tuned.
RADIO [6L]: Access to the RADIO top level page where NAV is located.
LIBRARY [6R]: Access to the NAV Library page.
NAVIGATION RADIOS (VOR Page 2/2)
This page allows the pilot to control the operation of 2 VOR and 2 DME radios.
NOTE: This page is only displayed if VOR-auto-tuning or radio test is configured.
Display the second VOR 2/2 page from the horizontal configuration by pressing [RADIO], <VOR#>, [NEXT].
NOTE: The VOR and DME ident suffix "x" (e.g. VOR, VOR1...) and the side (left or right) where the VOR/DME
units appear is depending on the installation configuration.
VOR1 MODE [1L]: Toggles VOR1 mode status for the VOR radio. The possible values are AUTOMATIC or
MANUAL.
VOR 2/2
VOR1 MODE VOR2 MODE
>AUTOMATIC MANUAL<
VOR1 TEST VOR2 TEST
>READY READY<
DME1 TEST DME2 TEST
>READY READY<
<RADIO
Page 13-10
August 17, 2010
To Next Page
