Esterline CMA-9000 - NAVIGATION DATA AND WAYPOINT MANAGEMENT

OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-38
August 17, 2010
NAV DATA 1/1 or 1/2
The NAV DATA 1/1 page allows for the display and partial modification of waypoint information from the
navigation, temporary, custom, or user databases. Fixed waypoints information may be viewed. It also provides
access to the USER WPT page for modification of all user waypoint parameters.
Display NAV DATA 1/1 page by pressing [INIT REF], and <NAV DATA>.
A. Display upon entry into the page (with no identifier being supplied from the previous page):
B. Display upon entry of an existing identifier in the user waypoint database. The displayed page differs
depending on the type and class. Large font used for modifiable fields:
1R
2R
3R
4R
5R
6R
NAV DATA 1/1
ID
-----
<NEW USER WPT
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
6R
NAV DATA 1/1
AFVRD WPT POS
N03
o
21.12 W123
o
25.56
BRG/DIS 134
T
/123NM
DATABASE USER
REGION CAN CY
TYPE/CLASS TACAN
ELEVATION +2309
FT
CHAN 126X
DECLIN W116
o
<EDT/NEW WPT
1L
2L
3L
4L
5L
6L
1R
2R
3R
4R
5R
6R
NAV DATA 1/1
AFVRD WPT POS
N03
o
21.12 W123
o
25.56
BRG/DIS 134
T
/123NM
DATABASE USER
REGION CAN CY
TYPE/CLASS TACAN
ELEVATION +2309
FT
CHAN 126X
DECLIN W116
o
<EDT/NEW WPT
1L
2L
3L
4L
5L
6L
