INTC CRS XXX° [6R]: Not shown in the page examples. Prompt appears on a Direct-To leg entry. A desired
inbound course to the Direct-To Waypoint may be entered by keying the course into the scratchpad and
pressing LSK 6R.
HOLD PPOS [6R]: Not shown in the page examples. Prompt appears on pressing of HOLD key in flight. Used
to define a Holding Pattern at present position. Access to the HOLD 1/X page.
NEXT LEG [6R]: Not shown in the page examples. Prompt is displayed when automatic waypoint sequencing
is not possible. Examples include when the active leg is vector, or an altitude-terminated leg without a Baro-
Corrected Altitude input. Pressing NEXT LEG results in an immediate transition of navigation and guidance to
the next waypoint in the flight plan.
CONFIRM [6R]: Confirm the changes made to the inactive route.
(SAVE?): Displayed between the CANCEL/CONFIRM prompts when the inactive route is in modification.
FAF,MAP,CTR: FAF is displayed when the waypoint is defined as the Final Approach Fix. MAP is displayed
when waypoint is defined as the Missed Approach Point. CTR also appears in the title when in MAP CTR STEP
mode. All are displayed in reverse white video.
RTE x LEGS ETA 1/X
Provides the ETA and EFA for each waypoint on the corresponding RTE LEGS Y/X page.
Display ACT RTE LEGS ETA Y/X page by pressing [LEGS] and <LEGS ETA>.
A. Normal ACTIVE format:
ACT RTE 1 LEGS ETA 1/4
ETA EFA (KG)
CAFTA 1916.4Z 1328
YZP 1950.2Z 1185
MOCA1
2000.7Z 1179
BKA
2044.5Z 950
KILLA
2127.0Z 792
<LEGS LEGS WIND>
To Next Page
