OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
Page A-77
August 17, 2010
E. Active route restored:
WAYPOINT IDENTIFIER [1L, 2L, 3L, 4L, 5L]: Displays the same identifiers as on the corresponding RTE
LEGS Y/X page.
ETA (1L,2L,3L,4L,5L): Displays ETA at the indicated waypoint when a vertical profile has been computed.
Value is displayed for the active and modified flight plan waypoints up and including to the runway waypoints, if
present. FMS-computed value is displayed in white small font. Data field displays dashes when no vertical
profile has been computed. The data field is blank for the inactive routes.
On Ground the field displays ETE instead of ETA and are blank.
LEGS [6L]: Access to the corresponding RTE LEGS Y/X page. To display the RTE LEGS 1/X page and the
active waypoint, press the LEGS function key.
ERASE [6L]: Erases route modifications (if any).
CANCEL [6L]: Cancel the changes made to the inactive route.
RESTORE [6L]: Displayed only if the route was erased on the RTE 1/X page. Used to restore the active route.
EFA (1R, 2R, 3R, 4R, 5R): Displays the Estimated Fuel Available (EFA) at the indicated waypoint when a
vertical profile has been computed. Values are displayed for the active and modified flight plan waypoints up
and including to the runway waypoints, if present. FMS-computed value is displayed in white small font. Data
field displays dashes when no vertical profile has been computed. The data field is blank for the inactive routes.
LEGS POS [6R]: Access to the corresponding RTE LEGS POS Y/X page. Display only if the fuel page is not
configured .
LEGS WIND [6R]: Access to the RTE LEGS WIND Y/X page. Displayed only if the fuel page is configured.
CONFIRM [6R]: Confirm the changes made to the inactive route.
ACT RTE 1 LEGS ETA 1/4
ETA EFA (KG)
CAFTA 1916.4Z 1328
YZP
1950.2Z 1185
MOCA1
2000.7Z 1179
BKA
2044.5Z 950
KILLA
2127.0Z 792
<LEGS LEGS WIND>
To Next Page
