OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
PERF INIT 1/1
The PERF INIT page is used to initialize the FMS with the required performance data for subsequent VNAV
performance calculations.
Display PERF INIT 1/X page by pressing [INIT REF] and <PERF INIT>
VNAV Performance Function before initialization.
The FMS is airborne. The TOGW field title changed to GWT and the BLOCK character string is removed.
Datafield at LSK 2L displays the current fuel quantity. The TAXI data field and title are removed.
1R
2R
3R
4R
5R
PERF INIT 1/1
TOGW CRZ ALT

BLOCK FOB CRZ TEMP
.MT 35.0MT ---ºC
ZFW CRZ WIND
.MT ---
T
/---KT
RESERVES
5.0
MT
TAXI TRANS ALT
0.4
MT 18000FT
<INIT/REF TAKEOFF>
1L
2L
3L
4L
5L
6L
6R
1R
2R
3R
4R
5R
PERF INIT 1/1
GWT CRZ ALT
44.8MT FL320
FUEL CRZ TEMP
7.0MT -49ºC
ZFW CRZ WIND
38.0MT 241
T
/35KT
RESERVES
0.5
MT
TRANS ALT
18000FT
<
INIT/REF RTE>
1L
2L
3L
4L
5L
6L
6R
Page RRJ-A-1
August 17, 2010
DRAFT
