EXTRA TIME [5R]: The fuel remaining and endurance time accounting for the fuel to the active route
destination, holding fuel and reserves. The endurance time is calculated at 1500ft above the airport and green
dot speed.
FUEL FLOW [6R]: Data field displays the Fuel Flow from the DECU and APU, if they are available.
ENG OUT CLB 1/5
The Engine Out CLB page is used to activate and display engine out Climb vertical mode data.
Predictions (i.e time, alt, fuel) are not provided while engine out climb mode is active
Press [VNAV], <ENGINE OUT> (When in Climb mode)
Press [VNAV] (When E/O climb mode is active)
NOTE(S):
• When the Engine Out climb page is accessed, while E/O mode is not active, the EXEC key illuminates and
MOD is displayed on the title page. This allows the pilot to confirm the selection of FMS engine out mode.
• The VNAV profile is failed and all predictions are removed when engine-out mode climb mode is active
A. Engine Out has been selected on the CLB page, E/O CLB page, E/O CLB page is displayed (MOD state).
1R
2R
3R
4R
5R
6R
MO
D
E/O CLB 1/5
CRZ ALT G-DOT CEIL
FL350 FL290
ING
G-DOT SPD LRC CEILING
240 FL270
<ERASE NO PROFILE
1L
2L
3L
4L
5L
6L
