OPERATOR’S MANUAL
CMA-9000 FLIGHT MANAGEMENT SYSTEM
2. Display the desired RUNWAY by pressing the PREV or NEXT key as required, and select the RUNWAY by
pressing the appropriate right hand LSK.
NOTE: Once a runway is selected, then only those SIDs applicable to that runway will be displayed.
3. Display the desired SID by pressing the PREV or NEXT key as required, and select the SID by pressing the
appropriate left hand LSK.
The SID list is replaced by the selected SID, with the legend "<SEL>" beside the name. Transitions available
for the selected SID are listed below the SID, under the heading "TRANS". If no transitions are available, the
word "-NONE-" is displayed. If no runway was selected, a list of runways applicable to the selected SID
appears on the right hand side of the page.
KBFI DEPARTURES 1/1
SIDS RTE 1 RUNWAYS
LACRES<SEL> <SEL> 13R
TRANS
HUMPPS
ORTIN
VAMPS
<ERASE ROUTE>
4. Display the desired SID transition by pressing the PREV or NEXT key as required, and select the transition
by pressing the corresponding left hand LSK.
The list of transitions is replaced by the selected transition, with the legend "<SEL>" beside the name.
NOTE: Any selected element can be changed by pressing the appropriate left/right hand LSK to re-display the
desired list (toggles the selection).
5. Display the first SID leg by pressing LEGS and PREV or NEXT as required.
KBFI DEPARTURES 1/1
SIDS RTE 1 RUNWAYS
LACRES<ACT> <ACT> 13R
TRANS
VAMPS <ACT>
<DEP/ARR ROUTE>
Page 4-5
August 17, 2010
