Hard disk drives / solid state drives
7.2 2.5-inch hard disk drives / solid state drives
7.2.1 Mounting order for 2.5-inch HDDs / SSDs
Maximum configuration: 4x 2.5-inch HDDs / SSDs
Figure 35: 2.5-inch HDD / SSD mounting order
7.2.2 Installing 2.5-inch HDD / SSD modules
7.2.2.1 Required tools
● Preliminary and concluding steps: tool-less
● Installing a 2.5-inch HDD / SSD module: tool-less
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
1
2
3
4
