TX120 S3 Upgrade and Maintenance Manual 297
Front panel and LAN connecto
r
13.1.4 Installing the front panel module
Figure 170: Inserting the front panel module
Ê Insert the new front panel module as shown and and carefully push in until
it locks in place.
Ê Open the front cage.
