TX120 S3 Upgrade and Maintenance Manual 423
16 Appendix
16.1 Mechanical overview
16.1.1 Server front
2.5-inch HDD model
Figure 279: PRIMERGY TX120 S3 front - 2.5-inch HDD model
Pos. Component Reference
1 2.5-inch hard disk drives /
dummy modules
"Mounting order for 2.5-inch HDDs /
SSDs" on page 121
2ID card
3 Optical disk drive "Mounting order for accessible drives"
on page 264
4 Backup drive
5 5.25-inch dummy module
6 Front panel module including
front USB connectors
"Replacing the front panel module" on
page 294
/
0
1
2
3
4
5
