TX120 S3 Upgrade and Maintenance Manual 321
System board and components
Figure 191: Installing the UFM board
Ê Connect the UFM board to the system board, snapping in the UFM spacer.
14.2.1.4 Concluding steps
Perform the following procedures to complete the task:
Ê Close the server cover as described in section "Closing the server" on
page 70.
Ê Reconnect the AC power cord to the power supply unit.
Ê Enable boot watchdog functionality as described in section "Enabling SVOM
boot watchdog functionality" on page 96.
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task, re-enable BitLocker as described in section "Enabling
BitLocker functionality" on page 103.
