TX120 S3
Upgrade and Maintenance Manual
195
Expansion cards and backu
p units
9.3.1.5
Connecting the BBU cable
Figure 92: Connecting the BBU to t
he controller
Ê
Connect the BBU cable to the controller (1).
Ê
Run the BBU cable through the middle cable bracket as shown (2).
/
0
194
196
