TX120 S3 Upgrade and Maintenance Manual 155
System fan and HDD fan
8.1.3 Removing the system fan module
Figure 60: Disconnecting the cable of the system fan module
Ê Disconnect the fan cable from system board connector FAN1 SYS.
Figure 61: Removing the system fan module
/
01
