232 Upgrade and Maintenance Manual TX120 S3
Expansion cards and backup units
9.4.2.3 Replacing SFP+ transceiver modules
For Fiber Channel over Ethernet (FCoE) configurations, the ethernet server
adapter is equipped with one or two SFP+ (small form-factor pluggable)
transceiver modules.
Required tools
● Preliminary and concluding steps: tool-less
● Removing SFP+ transceiver modules: tool-less
Removing SFP+ transceiver modules
Ê Remove the defective SFP+ transceiver module(s) as described in section
"Removing an SFP+ transceiver module" on page 230.
Installing SFP+ transceiver modules
Ê Unpack the new SFP+ transceiver module.
Ê Verify that the new SFP+ transceiver module is the same type of transceiver
you are replacing.
Ê Install the replacement SFP+ transceiver module(s) as described in section
"Installing SFP+ transceiver modules" on page 224.
Ê Inform the customer about changed WWN and MAC addresses.
I By replacing SFP+ transceiver modules, WWN (World Wide Name)
and MAC (Media Access Control) addresses will change.
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
