364 Upgrade and Maintenance Manual TX120 S3
Cables
15.1 Cabling overview
15.1.1 Overview of used cables
No. Name Number Routing 2.5"
HDD
model
3.5"
HDD
model
1
Front panel
connector cable
T26139-Y4015-V1
from front panel
module to system
board
oo
2 Power cable
T26139-Y4012-
V501
from all drives to
system board
oo
3 ODD SATA cable
T26139-Y3928-
V205
from optical disk drive
to system board
oo
4 SAS / SATA cable
T26139-Y3963-
V113
from 2.5-inch HDD
backplane to system
board
o
5 SATA Y-cable
T26139-Y3964-
V201
from 3.5-inch HDDs
to system board
o
6
IF BBU installed:
BBU cable (I
2
C bus)
T26139-Y3987-V2
from BBU to RAID
controller
oo
IF FBU installed:
FBU adapter cable
T26139-Y4032-V1
from FBU to RAID
controller
oo
7a USB cable T26139-Y3973-V95
from USB backup
drive to system board
oo
7b USB 3.0 cable T26139-Y4039-V80 from USB backup
drive to USB 3.0
interface card
(optional)
oo
8 Front LAN cable T26139-Y4025-V1
from server front to
front LAN board
D2935
oo
Table 8: List of used cables
