306 Upgrade and Maintenance Manual TX120 S3
Front panel and LAN connector
Figure 181: Connecting front panel cables (B)
Ê Before installing the server cover break out the front LAN cover plate on the
front cover.
I Please note that once removed, the front LAN cover plate cannot be
refitted.
13.2.1.5 Concluding steps
Ê Close the front cage as described in section "Closing the front cage" on
page 68.
Ê Close the server cover as described in section "Closing the server" on
page 70.
Ê Reconnect the AC power cord to the power supply unit.
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task, re-enable BitLocker as described in section "Enabling
BitLocker functionality" on page 103.
